LCM M-S

Chocolate melting container

If you want to have liquid chocolate permanently available, a chocolate dissolver is recommended. The LCM M-S is available in different versions, which can be found under technical data.





Features

  • Chocolate dissolver with different tank sizes
  • Agitator with interval control - removable for easy cleaning
  • Drain cock heated

Ausstattung

  • Automatic shutdown of the individual heating circuits depending on the filling quantity
  • Electrical direct contact heaters insulated to the outside ensure accurate temperature values and reduce energy consumption
  • Heated drain tube with drain cock - temperature adjustable
  • Smooth start-up of the agitator due to the use of a frequency converter, resulting in low stress on the mechanical components and a long service life
  • Slow rotating stable agitator, removable for cleaning
  • Agitator drive at the bottom of the tank
  • Machine housing made of stainless steel, mobile on stable swivel castor
Capacity (kg)Width (cm)Depth (cm)Height of machine (cm)el. Connection (V/kW)Weight (kg)
LCM 100 M-S1008278120400/1,6120
LCM 200 M-S2008278130400/1,8140
LCM 400 M-S400   400/2,2180
LCM 600 M-S600   400/2,6240
Do you have any further questions? We will be glad to help you!
